김병국 Byoung-kug Kim , 차용훈 Yonghoon Cha , 홍성화 Sung-hwa Hong , 이재호 Jaeho Lee

DOI: JANT Vol.27(No.5) 495-501, 2023

---

P-3C/K aircraft for maritime patrols that Republic of Korea Navy is using, is equipped with a variety of sensors and communication devices. Collected data from the aircraft is managed as tactical information by flight operators and stored. When the flight mission is completed, this information is transferred to tactical support center on the ground and played back or used for follow-up work through a analysis tool. During a flight mission, there are tens of thousands of detection objects within an hour in KADIZ (Korea air defense identification zone). In contrast, in TSD (tactical situation display), which displays a map when using the analysis tool, all detected objects are expressed as symbols. The increase in display symbols has a significant impact on the TSD image updating and consequently interferes with the smooth operation of operators. In this paper, we propose applying multiple threads and multiple layers to improve the performance of existing TSD. And the performance improvement is proven through the execution results.

이성섭 Soung-sub Lee , 김종필 Jong-pil Kim , 유응노 Eung-noh You , 윤재혁 Jae-hyuk Youn , 신호현 Ho-hyun Shin

DOI: JANT Vol.27(No.5) 502-509, 2023

---

This study presents a satellite constellation method that achieves optimal revisit performance by utilizing genetic algorithm techniques. The Walker method is a global coverage concept, and there are limitations to target-centered constellation considering the strategic environment of the Korean Peninsula. To overcome these limitations, targets are set in major areas of interest in North Korea, orbit elements with optimal revisit performance for each target are searched, and based on this, the number of satellites optimized for each target is derived using a genetic algorithm. The results of this study demonstrate the performance of the optimized constellation by applying phasing rules to achieve the desired revisit performance.

박재욱 Jaeuk Park , 김부겸 Bu-gyeom Kim , 기창돈 Changdon Kee , 김동욱 Donguk Kim

DOI: JANT Vol.27(No.5) 510-518, 2023

---

This paper introduces a MATLAB graphical user interface (GUI) based software for performance analysis of navigation message and wide area differential correction of regional navigation satellite system (RNSS). This software was developed to analyze satellite orbit/clock-related performance of navigation message and wide area differential correction simulating RNSS for regions near Korea based on different distributions of monitor and reference stations. As a result of software operation, navigation message and wide area differential correction are given as output in MATLAB file format. From the analysis of output, it was confirmed that valid navigation message and wide area differential correction could be generated from the results about statistical feature of orbit and clock prediction errors, cm-level fitting errors for navigation message parameters, and 81.9% enhancement in range error for wide area differential correction.

이유진 Yu-jin Lee , 정재원 Jae-won Jung , 임진식 Jin-shik Lim , 김길훈 Kil-hun Kim

DOI: JANT Vol.27(No.5) 519-527, 2023

---

Air-launch means launching from aircraft such as fighter jets, and has various advantages, such as cost reduction and less environmental/weather impact during launch. However, there are no air-launch satellite in Korea. Examining air-based launch satellite and anti-satellite missiles operated and developed by foreign private companies and various countries confirmed the necessity of domestic research and development. In South Korea, various research activities, including satellite launch system design and development approaches for different launch platforms, have been carried out mainly by academia. Development of upward maneuver air launch technology which is launched in the air when the aircraft is moving upward is suggested. Additionally, an introduction to wind tunnel tests for safety separation verification is provided. A new concept for a test facility has been suggested to conduct drop tests.

최지헌 Jihun Choi , 김성엽 Sung-yeob Kim , 김현덕 Hyeon-deok Kim

DOI: JANT Vol.27(No.5) 528-533, 2023

---

Airlines tried to introduce training programs in connection with practical work in order to provide more effective education and training. To this end, airlines have been conducting evidence-based training(EBT) to strengthen the practical capabilities of aviation personnel and enhance safety culture. Airlines can systematically evaluate the capabilities and practical capabilities of aviation personnel by analyzing operational data and case studies for effective EBT model development. In addition, EBT models can be constructed by applying technical methods such as crew resource management (CRM) and a holistic approach that includes human factors. Due to the introduction of EBT, airlines will establish diagnostic and feedback systems for pilots' practical work, provide personalized education, and establish an education and training system that verifies the effectiveness of education through educational outcomes.

김성엽 Sung-yeob Kim , 최지헌 Jihun Choi , 이명식 Myeong-sik Lee , 김현덕 Hyeon-deok Kim

DOI: JANT Vol.27(No.5) 534-539, 2023

---

Currently, in Korea, to obtain a jet type rating, you must receive training on a small business jet model. The reason is because of the law in the Aviation Safety Act Enforcement Rules 『Appendix 4』 that states, “You must receive at least 2 hours of flight training.” In the end, it is acquiring type rating as a small business jet aircraft with relatively low operating costs. The qualifications acquired in this way are different from those for aircraft operated by airlines. However, if you have an initial jet type rating, you can acquire an airline aircraft qualification just by training on a simulator, so airlines want you to have at least a small-jet type rating. However, in the United States and Australia, there is a system in place to acquire initial jet type rating through simulator training without actual flight training.

김용민 Yong-min Kim , 노지은 Ji-eun Roh , 원진주 Jin-ju Won

DOI: JANT Vol.27(No.5) 540-545, 2023

---

AESA radar is able to instantaneously and adaptively position and control the beam, and this enables to have interleaved mode in modern airborne AESA radar which can maximize situational awareness capability. Interleaved mode provides two or more modes simultaneously, such as Air to Air mode and Sea Surface mode by time sharing technique. In this interleaved mode, performance degradation is inevitable, compared with single mode operation, and effective resource allocation is the key component for the success of interleaved mode. In this paper, we identified performance evaluation items for each mode to analyze interleaved mode performance and proposed effective resource allocation methodology to achieve graceful performance degradation of each mode, focusing on detection range. We also proposed beam scheduling techniques for interleaved mode.

곽용길 Yong-kil Kwak

DOI: JANT Vol.27(No.5) 546-551, 2023

---

In this study, a beam steering measurement system was developed to perform functions such as far-field beam steering and near -field beam focusing for TX/RX modes in the near file of the AESA radar. The beam steering measurement system consists of a spherical near-field scanner, an antenna positioner, a near-field controller, a network analyzer, a radar control system, a verification radar, a simulated radio, and an AESA radar. Using the developed system, the characteristics of TX/RX patterns before and after installation of radome to AESA radar were measured, and the beam pattern was analyzed through conversion to far field-after near-field measurement. The boresight error of the radar antenna device was measured, and it was confirmed that the main lobes were formed the same before and after the simulated radar dome was mounted.

김종부 Jongboo Kim , 이두열 Dooyoul Lee

DOI: JANT Vol.27(No.5) 552-560, 2023

---

Aircraft midair collisions are dangerous events that can cause massive casualties. To prevent this, civil aviation has mandated the installation of TCAS (ACAS), which is becoming more sophisticated with the help of new technologies. However, there are institutional problems in collecting data for TCAS research in Korea, limiting the ability to obtain data for personal research. ADS-B and Mode-S automatic broadcast various information about the flight status of the aircraft. This data also contains information about TCAS RA, which can be used by anyone to find examples of TCAS RA operation. We used the databases of ADS-B Exchange and Opensky-Network to acquire data and visually represent three TCAS RA cases through Python coding. We also identified domestic TCAS cases in the first half of 2023 and analyzed their characteristics to confirm the usefulness of the data.

김연실 Youn-sil Kim , 배중원 Joong-won Bae

DOI: JANT Vol.27(No.5) 561-567, 2023

---

In this study, the collision risk of the UAM (Urban Air Mobility) corridor was analyzed using a collision risk model applied to the manned aircraft corridor. According to the K-UAM roadmap and operating concept, UAM is expected to fly on a designated route similar to existing manned aircraft operations and operate on two routes, traveling back and forth between the departure point and the destination point. Among domestic manned aircraft routes, the manned aircraft operation between Gimpo Airport and Jeju Airport is similar to this and takes the form of a parallel route with a lateral separation distance between the two routes. In this study, we analyzed the collision risk of the UAM corridor according to the lateral separation distance using a collision risk model used to analyze the collision risk of manned aircraft parallel routes for a similar type of UAM corridor. Based on this, we finally analyzed how many parallel routes could be installed within the width of the Han River, considering the K-UAM demonstration route.
